Name: P6 Outdoor Full Color LED Display Screen SMD 3535 6500cd/sqm
Brand: SHENZHEN KAILITE OPTOELECTRONIC TECHNOLOGY CO., LTD
SKU: पी 6
Price: 400.00 USD
Availability: InStock

होम उत्पाद आउटडोर विज्ञापन प्रदर्शित एलईडी

P6 Outdoor Full Color LED Display Screen SMD 3535 6500cd/sqm

उत्पाद विवरण:

उत्पत्ति के प्लेस:	ग्वांगडोंग, चीन
ब्रांड नाम:	KAILITE
मॉडल संख्या:	पी 6

भुगतान & नौवहन नियमों:

न्यूनतम आदेश मात्रा:	2

संपर्क करें

विस्तृत उत्पाद विवरण

पिक्सेल पिच:	6 मिमी	मॉड्यूल आकार:	192*192 मिमी
भौतिक घनत्व:	27777 डॉट्स/स्क्वायर मीटर	पिक्सेल विन्यास:	1R1G1B
एलईडी चिप:	Smd3535	मॉड्यूल संकल्प:	32*32
मॉड्यूल शक्ति:	35W	देखने का दृष्टिकोण:	H: 120 °; V: 120 °
इष्टतम दूरी:	6-70 मीटर	अधिकतम शक्ति:	900W
कैबिनेट आकार:	डब्ल्यू: 960 मिमी*एच: 960 मिमी	कैबिनेट संकल्प:	96*96
ड्राइविंग पद्धति:	निरंतर वर्तमान 1/4 स्कैन	फ्रेम आवृत्ति:	≥60 हर्ट्ज
ताज़ा आवृत्ति:	≥1200 हर्ट्ज
प्रमुखता देना:	P6 outdoor LED display screen , SMD 3535 LED display , 6500cd/sqm outdoor LED screen

Stage Background Die Casting Aluminum P6 Full Color Outdoor LED Display Screen for Concert

Product Attributes

Attribute	Value
Use	Outdoor
Tube Chip Color	FULL COLOR
Display Function	Video
Pixels	6mm
Screen Dimension	Customized Size
Product Name	Factory direct led tv full color smd screen sign outdoor p6
Brightness	6500cd/sqm
Application	Outdoor
LED Chip	SMD 3535
Module Size	192*192mm
Certificate	CE RoHS FCC Certifications
Viewing Angle	H120° V120°
Life Span	100000 hours
Warranty	2 years
Driving Method	1/8 Scan Constant Current

Product Description

LED technology has revolutionized visual displays worldwide. As a premier application of this technology, our LED screens deliver exceptional visual and auditory experiences, transforming events into vibrant spectacles.

SHENZHEN KAILITE OPTOELECTRONIC CO.,LTD specializes in manufacturing high-quality LED displays. We provide complete, customized LED screen solutions at competitive prices with guaranteed quality.

Key Features

Customized solutions tailored to your specific requirements
Factory-direct pricing with superior quality
Quick and easy installation with simple maintenance
2-year comprehensive warranty

Technical Specifications

Item	P6
Pixel Pitch	6mm
Module Size	192*192mm
Physical Density	27777dots/sqm
Pixel Configuration	1R1G1B
LED Chip	SMD3535
Module Resolution	32*32
Module Power	35w
Viewing Angle	H:120°;V:120°
Optimal Viewing Distance	6-70m
Maximum Power	900w
Cabinet Size	W:960mm*H:960mm
Cabinet Resolution	96*96
Driving Method	Constant current 1/4 scan
Frame Frequency	≥60Hz
Refresh Frequency	≥1200Hz
Brightness	≥6500cd
Operation Temperature/Humidity	-30℃~+45℃ 10%~95%
Input Voltage	220V±10%/110V±10%
Ingress Protection	Front IP:67:Back IP:65
Gray Scale/Color	≥16.7M color
Brightness Control	Manual/Automatic
Input Signal	RF/S-Video/RFB/etc.
Control System	PCTV+DVI video card control card fiber
MTBF	>5,000hrs
Life Time	>100,000 hours
Lamp Failure Frequency	<0.0001
